Acoustic Ceiling Clouds

Acoustic Ceiling Clouds are cloth wrapped compressed fiberglass acoustic panels that float from the ceiling rather than flush mount to a surface.  By floating the panels, our clients are able to first, leave their walls as they are, and second, expose the backside of the acoustic ceiling clouds to more air to heighten the panel’s ability to capture and convert more echo from a space.   A popular item for noise infested rooms where available wall space is limited, or the client has the preference to create ceiling soundproofing rather than apply acoustic panels to the perimeter walls.

Questions?  Call 1-800-638-9355

Floating Sound Panels

Just as with our other acoustic panels, success with Acoustic Ceiling Clouds is based on having the correct number of sound panels for your room’s size, shape and surface textures.   Our acoustic ceiling clouds are colorful, durable, class A fire rated, and easy to self install.   You can float them as close to the ceiling as you want to trigger the intended sound values.   Free color swatches available to help you choose the right color.

We run a complimentary Room Analysis for our customers to help get that calculation right.   See the link below.

Color Chart Color Swatches

Ceiling Cloud Prices

Ceiling Clouds can be cut to any size up to a maximum of 4’x 10’. The panel dimensions shown here represent our standard size Clouds, but you can submit your own dimensions as you wish.   The automatic default on the prices listed include a soft, square edge.   Add $5 per panel for hardened edge.  Add $10 per panel for mitered or rounded edge.

Questions?  Call 1-800-638-9355

Panel Size
1" thick
2" thick
2' x 4'
$100
$120
2' x 5'
$120
$135
2' x 6'
$135
$145
2' x 7'
$150
$165
2' x 8'
$170
$185
2' x 9'
$190
$205
2' x 10'
$210
$225
4' x 3'
$120
$145
4' x 4'
$165
$195
4' x 5'
$195
$235
4' x 6'
$225
$275
4' x 7'
$245
$310
4' x 8'
$275
$335

Installing Ceiling Clouds

Your Acoustic Ceiling Clouds will come equipped with the hardware attached to the backside of the sound panels.   Simply thread your own thin gauge wire through the hardware and anchor mechanically to your ceiling as you wish.   Any distance down from the ceiling works as well as any other.   Be sure to stay clear of lighting, sprinkler heads and any HVAC or pipes you have in your ceiling. The goal is nice even site lines, once we have the right amount of material calculated and delivered to your project site.   Clouds are lightweight. A standard 3’x4′ panel will weigh about 5 pounds.

1-800-638-9355

Ceiling Cloud Tips

Ceiling Clouds are designed to suspend mechanically from your ceiling to lower the ambient levels of echo in your space.   This is an ideal soundproofing treatment where available wall space is limited, or clients want their walls left alone.   By floating these soundproofing panels out over the expanse of a ceiling, in nice even site lines, the panels combine to create a decorative look to the space as well as curb the excessive levels of noise.   Pay attention to your panel thickness. Go 1” thick for rooms filled primarily with human voice, and upgrade to the 2” thick sound panel if you have music in the room.

Questions?  Call 1-800-638-9355

See Case Studies

Sound Test Results

Frequency
125
250
500
1k
2k
4k
NRC
1"
.14
.27
.80
1.11
1.14
1.14
.85
2"
.22
.81
1.24
1.30
1.21
1.16
1.15
125
250
500
1k
1"
.14
.27
.80
1.11
2"
.22
.81
1.24
1.30
2k
4k
NRC
1"
1.14
1.14
.85
2"
1.21
1.16
1.15
Spec Sheet

This product is class A fire rated and approved for use in any public venue.

* Test results available upon request

Shipping

Ceiling Clouds will be bundled and edge protected, boxed up and shrunk wrap on pallets prior to shipment.   Care should be given upon delivery, be sure to carefully inspect your shipment before your driver leaves.   If you see any potential damage to your order, be sure to sign for as such while your driver is still there.   It happens only on rare occasions, but if your panels are damaged, our only recourse is to replace the panels at the expense of the freight company, which only happens if you sign for the delivery as damaged.   Be sure to notify our help desk if you need a lift gate for ease in delivery.

Shipping/Receiving Terms & Conditions

Step #1:   Room Analysis

Use this popular tool to calculate how many Ceiling Clouds you need.   The key to the success of your soundproofing treatment is to ensure that you do not under treat your space.

Room Analysis Quote

Your Room Analysis

The key to the success of your sound panel treatment lies with getting the coverage amounts right. Our goal is to safeguard against under treating your space and conceding sound values back. Please submit the information below, and we will report back with the results of your Room Analysis, and quote your Ceiling Cloud project.
